EVOS™ XL Core Imaging System

EVOS™ XL Core Imaging System

The EVOS XL Core Imaging System is a digital transmitted-light inverted imaging system for cell and tissue culture applications and routine cell maintenance. Its simple user interface drives a color camera and high-quality optical system that delivers high-definition images with exceptional ease. Equipped with 4X, 10X, 20X, and 40X long-working–distance (LWD) phase contrast (PH) objectives and a mechanical stage, the all-in-one EVOS XL Core system is an ideal microscope for basic imaging needs. With a small footprint, an articulated LCD monitor, and ergonomic design, it is a perfect addition to any cell culture room or facility.

Features

• Easy installation; no maintenance, assembly, alignment, or calibration.
• 4X, 10X, 20X, and 40X LWD PH objectives that are ideal for tissue culture microscopy.
• A mechanical stage for precise vessel positioning, including of multi-well plates.
• Fits and operates inside cell culture hoods.
• All-in-one design: digital camera, precision optics, LCD display, and USB storage

Contents

• EVOS XL Core Imaging System (AMEX1000).
• EVOS XL Core Attachable Mechanical Stage (AMEP4712).
• Achro 4X LWD PH, 0.13NA/16.9WD (AMEP4932)
• Achro 10X LWD PH, 0.25NA/6.9WD (AMEP4933)
• Achro 20X LWD PH, 0.40NA/6.8WD (AMEP4934)
• EAchro 40X LWD PH, 0.65NA/3.1WD (AMEP4635)
• Wireless mouse.
• Power adaptor, cord, and universal power plug adapters
• USB flash drive (includes User Guide and Quick Start Guide)
• Dust cover.
• 3-mm hex driver L-shaped key
• Mechanical stage instructions
